Lining
FRP Lining
Seamless glass-fiber reinforced plastic (FRP / GRP) composite lining systems applied on steel, concrete, and brick structures for heavy chemical, acid, and wastewater corrosion protection.
Specifications
- Laminate Thickness
- 3-ply (approx 3mm), 5-ply (approx 5mm), heavy duty 7-ply structural lining (>7mm)
- Barcol Hardness
- ≥ 35 Barcol
- Temperature Resistance
- Up to 120°C continuous wet immersion depending on resin selection
Description
FRP Lining
High-performance Fiberglass Reinforced Plastic (FRP/GRP) composite lining systems applied on-site or in-shop by PT Misuba Guna Indonesia to restore and protect chemical storage tanks, concrete neutralization pits, scrubber vessels, and floor trenches from severe chemical attack. Formulated with premium corrosion-grade vinyl ester, bisphenol, or novolac resins reinforced with C-glass surface tissue and E-glass chopped strand mats, our FRP linings create a continuous structural barrier that seals against liquid leaks and atmospheric fumes.
FRP lining is the ideal cost-effective solution for refurbishing corroded carbon steel tanks and waterproofing concrete bund walls against aggressive acids, alkalis, and industrial effluents.
Custom Engineering Consultation & Ordering Guide
When requesting an FRP lining evaluation for concrete or steel structures, provide the substrate type (new vs corroded steel, concrete grade), chemical exposure details (concentration, pH level, temperature), and total surface area in square meters. PT Misuba Guna Indonesia performs site inspection, surface grinding/moisture check, multi-layer lamination, and spark testing.
Features
- Custom resin selection (Vinyl Ester, Novolac, Isophthalic) matched to specific acid, solvent, or alkali exposure
- Monolithic, jointless composite lining seals concrete cracks and prevents chemical seepage into surrounding groundwater
- High mechanical strength-to-weight ratio allows structural rehabilitation of thin-wall corroded steel tanks
- Integral C-glass synthetic surface veil provides a resin-rich (>80%) chemical barrier preventing fiber prominence
- Excellent thermal expansion match with concrete and steel, preventing delamination during seasonal temperature cycles
Applications
- Chemical plant primary and secondary containment dikes, bund walls, and floor trenches
- Wastewater treatment plant (WWTP) equalization tanks, clarifiers, and acid neutralization pits
- Power plant demisalization water storage tanks and chemical dosing sumps
- Pulp and paper chemical storage vessels and bleach plant effluent gutters
- Electroplating acid rinse tanks and battery room floor protection
Materials
- Resin Matrix: Novolac Vinyl Ester (Derakane 470/411), Bisphenol A, Premium Isophthalic Polyester
- Reinforcement: E-glass Chopped Strand Mat (CSM 300/450/600 g/m²), Woven Roving (WR 600), C-glass surface veil
- Primers: Moisture-tolerant epoxy primer for concrete, Silane-treated steel primer
FRP Lining: common questions
Where is FRP Lining used?
Chemical plant primary and secondary containment dikes, bund walls, and floor trenches; Wastewater treatment plant (WWTP) equalization tanks, clarifiers, and acid neutralization pits; Power plant demisalization water storage tanks and chemical dosing sumps; Pulp and paper chemical storage vessels and bleach plant effluent gutters; Electroplating acid rinse tanks and battery room floor protection.
What materials are available for FRP Lining?
Resin Matrix: Novolac Vinyl Ester (Derakane 470/411), Bisphenol A, Premium Isophthalic Polyester; Reinforcement: E-glass Chopped Strand Mat (CSM 300/450/600 g/m²), Woven Roving (WR 600), C-glass surface veil; Primers: Moisture-tolerant epoxy primer for concrete, Silane-treated steel primer.
What do you need to quote FRP Lining?
Equipment to line (tank, vessel, duct, floor) and surface area; Chemical medium and concentration; Operating temperature; Substrate (steel or concrete) and its current condition; Site location and preferred schedule.
Who supplies FRP Lining in Indonesia?
PT Misuba Guna Indonesia supplies FRP Lining to industrial plants across Indonesia from its base in Tangerang, Banten. Send your operating conditions and quantity to sales@misubaguna.com or WhatsApp +62 811-8715-671 for a quotation.
Need a price, sizing or a drawing for FRP Lining?
Send your operating conditions and quantity. Our sales team will check the details and quote.
