Thermal Systems
Cooling Tower
Induced-draft counterflow and crossflow cooling towers in FRP, timber or concrete, sized to your heat load and wet-bulb conditions.
Specifications
- Typical capacity
- from small modular cells up to several thousand m³/h per tower
- Typical cooling range
- 5–10 °C, with approach to wet-bulb of 3–6 °C
- Drift loss
- typically 0.001–0.005% of circulating flow with low-drift eliminators
- Design wet-bulb
- set to local site conditions
Capacity, number of cells and fan power configured to your duty
Description
Industrial Cooling Towers: Counterflow & Crossflow
A cooling tower rejects process heat by evaporating a small part of the circulating water. We supply induced-draft towers sized to your heat load, flow rate and local wet-bulb temperature, in the structure and fill that suit your water quality and duty cycle.
Tower Types
- Counterflow: air rises against falling water through the fill. Compact footprint and high thermal efficiency, suited to clean circulating water.
- Crossflow: air crosses the falling water horizontally. Lower pumping head and easy access to the distribution basin, suited to dirtier water and sites needing low fan power.
- Modular and field-erected: factory-built cells for quick installation, or field-erected towers for large heat loads that are built cell by cell.
Core Components
- Fill: PVC or PP film fill for clean water, or splash fill where the water carries solids, oil or scale.
- Drift eliminators: cellular PVC or PP blades that keep water carry-over at a fraction of a percent of circulating flow.
- Fan and drive: axial FRP fan with gearbox or belt drive and a TEFC motor, with vibration cut-out as an option.
- Water distribution: spray nozzles or gravity-fed basin for even loading across the fill.
- Basin and casing: structure sized for the water volume, with access doors, ladders and handrails.
Keeping It Running
Fill fouling, basin leaks and gearbox wear are what cost a tower its performance. Our field team handles cooling tower repair, fill replacement and fan drive alignment, so one supplier covers both the new tower and its upkeep.
Features
- Sized to your heat load, range, approach and design wet-bulb temperature
- Counterflow, crossflow, modular and field-erected configurations
- Corrosion-resistant FRP structure that suits humid, chemical and coastal sites
- Low-drift eliminators that limit water loss and plume carry-over
- Efficient axial fans with variable speed drive as an option
- Replacement towers designed to fit existing basins and piping
Applications
- Process cooling in chemical, petrochemical and food plants
- Condenser water for power generation and cogeneration
- Air-conditioning and chiller plant heat rejection
- Plastics, injection molding and compressor cooling
- Pulp, paper and textile mills
Materials
- FRP, hot-dip galvanized steel, timber or reinforced concrete structure
- PVC or PP fill and drift eliminators
- FRP or aluminium fan blades
- Stainless steel or hot-dip galvanized fasteners
- HDPE, PVC or stainless steel distribution piping and nozzles
Cooling Tower: common questions
Where is Cooling Tower used?
Process cooling in chemical, petrochemical and food plants; Condenser water for power generation and cogeneration; Air-conditioning and chiller plant heat rejection; Plastics, injection molding and compressor cooling; Pulp, paper and textile mills.
What materials are available for Cooling Tower?
FRP, hot-dip galvanized steel, timber or reinforced concrete structure; PVC or PP fill and drift eliminators; FRP or aluminium fan blades; Stainless steel or hot-dip galvanized fasteners; HDPE, PVC or stainless steel distribution piping and nozzles.
What do you need to quote Cooling Tower?
Water flow rate (m³/h) or heat load; Hot water, cold water and design wet-bulb temperatures; Application (process, power, HVAC) and water quality; Site space, location and any noise limits; New unit, replacement or upgrade.
Who supplies Cooling Tower in Indonesia?
PT Misuba Guna Indonesia supplies Cooling Tower to industrial plants across Indonesia from its base in Tangerang, Banten. Send your operating conditions and quantity to sales@misubaguna.com or WhatsApp +62 811-8715-671 for a quotation.
Need a price, sizing or a drawing for Cooling Tower?
Send your operating conditions and quantity. Our sales team will check the details and quote.
